PLATINUM 24 Great Lakes Edition

testing a device Operator's manual Data sheet

Clearing Width: 61 cm / 24"

Traction Drive: Mechanical

The powerhouse for lots of snow

Pure power against snow. When you get behind your PLATINUM, you’ll want to keep going – driveway after driveway. These units were built for high-volume workloads, hence their standard hand-warmers and Super High Output (SHO) impellers. The PLATINUM Series is loaded with plenty of other features sure to fit your snow removal needs.

Built for high altitudes, this EFI powered machine will deliver the performance you need and exceed your expectations
369cc Ariens AX EFI engine
Wide 61cm (24”) clearing width that moves 73 tonnes of snow per hour
Blows snow from 0.9 – 17 m
Premium features like an LED light bar and headlight, handwarmers, electric chute control, electric start, and one-hand interlock

Einsätze

AutoTurn® SHO blower wheel Electric start

Features & Benefits

Heated handgrips

Dash-controlled heated handgrips keep your hand warm for greater control and extra comfort for longer.

Auto-turn steering

Drive straight ahead with the rear axle locked for maximum grip. As soon as you steer the machine, the axle is unlocked and turning on the spot is child's play. A patented invention from Ariens.

EFI Engine

The Electronic Fuel Injected (EFI) engine starts easier and is more fuel efficient without compromising on performance.

Available on the Platinum series models.

LED Headlight

Ultra-bright lighting comes standard on all Platinum Series Sno-Thro® models.

SHO Impeller

Super High Output (SHO) impeller throws snow far and fast, up to 83 tonnes/hour, allowing the auger to pull in more snow.

Quick-Turn chute rotation

Turn your chute instantly with the push of a button.

Warranty

Ariens is known across the globe for manufacturing durable, high-performance machines – and our warranty system in the EMEAA region reinforces that reputation. When professionals and homeowners invest in Ariens Zero-Turn mowers or snow throwers, they aren’t just buying powerful equipment – they’re gaining access to one of the most trusted warranty programs in the industry.

Technical Data

Model Number 921333

Engine Ariens AX 369 cm³ EFI

Stage Type Two Stage

Engine Displacement 369

Maximum Power 7,5 / 10,2 kW/hp @ 3,650 rpm

Max. Torque 23,1 Nm

Starting System 230 V & Recoil

Traction Drive Mechanical

Drive Axle Auto-Turn

Gears Forward / Reverse 6 / 2

Clearing Width 61 cm / 24"

Throwing distance 0.9 - 16.7 m

Tonnes per hour 73

Chute Rotation Electric, 200°

Auger Diameter 35.6 cm

Auger Type Steel Serrated

Auger housing 24" (61 x 53 cm)

Tyre size 16 x 4.8-8"

LED Light 1

Handle heating

Double belt drive

SHO impeller

Skid Shoes Steel Reversible

Scraper Bar Steel Adjustable

Deflector Control Remote

Lenght 148

Width 67 cm

Height 117 cm

Weight 130 kg

Gear Case Warranty 5 Year Residential / 1 Year Commercial

Product Warranty 3 Year Residential / 90 Day Commercial

Changes in technology, equipment and price are reserved. Of information or illustrations no claims can be derived.

Accessories

Snow cab

Protect yourself from the elements with a spacious, rugged, steel-frame Ariens Sno-Thro® cab. For all models.

Snow chains kit

Ulra-grip snow chains for strong traction on ice and packed snow. Available for all wheels.

Non abrasive skid shoe

Durable polyethylene material providing protection on decorative and sensitive surfaces around your home from scratches and damage.

LED dash headlight

Ariens OEM LED headlight replacement kit to be used on all Ariens snow-blowers model years 2011 and newer that have halogen light original.

Front weight kit - 4,5kg

In case of firm snow, the additional weight on the auger housing increases the pressure of the scraper edge to the ground.

Drift cutter kit

For high and heavy snowdrifts. The blades cut lateral snow that is higher than the diameter of the auger. For DELUXE, PLATINUM and PROFESSIONAL.

Clean out shovel with brush

The Ariens Clean-Out Tool cleans snow and ice from the discharge chute and impeller of your Ariens snow blower.

Snow Clean out shovel

If there is built-up snow and ice on the discharge chute and impeller of your Ariens Sno-Thro, the Clean-Out Spaded Tool is the perfect accessory to help remove it.

Cover snow blower

Designed to protect your investment, the Ariens snow cover provides year-round protection for your Ariens snow blower. Ariens covers are constructed of tough, durable, washable and tear-resistant 300 denier polyester.
