EDGE 42

testing a deviceOperator's manualData sheet
Cutting Width: 107 cm (42")
Deck Type: Side Discharge

Perfectly Balanced for Power and Maneuverability to Tackle Any Lawn with Ease

Enjoy the benefits of a zero-turn mower in your garden. Mow with more manoeuvrability and comfort than a lawn tractor and have fun doing it. Made for small to medium gardens with narrow passages.

The EDGE 42 comes with a premium Ariens 635cc engine and 107 cm (42″) fabricated cutter deck. It is perfect zero turn mower for medium size gardens.

  • The EDGE 42 features a 107cm (42″) fabricated deck constructed of strong 11-gauge steel
  • Powered by an Ariens 635cc engine​​
  • Foot-operated deck lift offers quick and easy cutting height adjustment
  • Four-point deck lift system offers unmatched stability and consistent cutting
  • High-back padded seat fitted as standard for operator comfort
  • A range of optional accessories is available
  • 2-year or 150 hours warranty

Einsätze

Private Petrol Optional mulching kit Ride-On (sitting) Side discharge Flat terrain Undulating terrain Hilly terrain Small areas Medium-sized areas

Features & Benefits

Intuitive controls

Control the two independently operating wheel drives with just two driving levers. You will be amazed at the precision and ease of this steering system. Every user will become a real zero-turn pro in no time at all. Try it out for yourself.

Very good quality of cut

Welded mowing deck of the EDGE 42” with two blades. Optional mulching kit.

Larger tyres

The large-diameter tires with a wide footprint offer greater traction and a smoother and more comfortable ride.

Comfort

The contoured seat of the EDGE has a large cut-out. This allows air to circulate, keeping your back dry and increase riding comfort in high outside temperatures.

Deck height lever

The cutting height can be adjusted in 7 stages from 3.8 cm to 11.4 cm using the easily accessible lever on the side of the seat. The cutting deck is raised conveniently using a foot pedal.

ARIENS engine

The EDGE is powered by the reliable Ariens 635 cm³ two-cylinder, Stage V, OHV engine.

Warranty

Ariens is known across the globe for manufacturing durable, high-performance machines – and our warranty system in the EMEAA region reinforces that reputation. When professionals and homeowners invest in Ariens Zero-Turn mowers or snow throwers, they aren’t just buying powerful equipment – they’re gaining access to one of the most trusted warranty programs in the industry.

weiterlesen

Technical Data

Model Number 915339
Engine Ariens OHV Twin Cylinder
Engine Displacement 635 cm³
Drive System Hydro-Gear® EZT® Transaxles
Maximum engine Power 14.5 kW / 19.4 hp at 3,600 rpm.
Fuel Capacity 7.5 l
Max. Speed Forward / Backward 9.6 km/h / 4.8 km/h (6 mph / 3 mph)
Deck Type, Rear discharge / Side discharge /
Mulching Kit optional
Deck Material 2.6 mm sheet steel with double thickness around blade support
Deck Construction welded
Deck Lift System foot operated
Number of blades 2
Spindle Material Steel
Spindles drive V-belt
Spindle Clutch Electric Warner®
Cutting Width 107 cm (42")
Cutting Hights 3.8 cm - 11.4 cm (1.5" - 4.5")
Cutting Positions 7
Front Wheels 11 x 4
Rear Wheels (inch) 20 x 8-8
Seat Padded seat w/ back cut-out
Hour Meter
Weight 232 kg
Length 173 cm
Width 140 cm w/ chute; 118 cm w/ mulch kit
Height 103 cm
Limited Warranty Machine 2 years / 150 hrs.
Changes in technology, equipment and price are reserved. Of information or illustrations no claims can be derived.

Accessories

Mulch kits

For installation in side discharge cutter decks. With every rotation of the blade, the mower sucks up grass in the closed cutting chamber, where the clippings are cut several times before they fall finely chopped onto the lawn.

Zero-turn cover

Protect your investment and extend the life of your equipment with an Ariens zero-turn cover. Fits EDGE, IKON XD and APEX models.

FLEXTEND™ shoulder support system

Gives additional support to the shoulder area when mowing for extended periods. For EDGE models.

Applications

featured-image

Private gardens

Ariens zero-turn mowers are not only for professionals and service providers, but also for private users. Zero-turn mowers are available in different sizes and cutting widths for private lawns from 1,000 m². The compact Ariens EDGE and IKON models are made for winding gardens and narrow driveways. Saving time is also the main advantage here. Mowing fun comes as standard.

» read on

featured-image

Janitorial services

The constantly changing activities of a janitor service are part of daily routine. Regular lawn mowing is often perceived as a chore and is particularly time-consuming. With a zero-turn mower, you'll be done faster. You can save up to 40% time compared to a conventional lawn tractor. The Ariens IKON is made for private gardens of any size or even semi-professional applications. For smaller janitor services, it is the ideal machine for mowing green spaces quickly and maneuverably.

» read on
